METER STAR CH85 Microwave High Voltage Capacitor, 1.05 µF 2100 VAC 50/60 Hz, CQC & VDE Certified, EN61270-1, 6.35 x 0.8 mm Terminals, No PCB, Replacement for GE WB27X10701

METER STAR CH85 microwave high voltage capacitor is a replacement repair component for household microwave ovens requiring a 1.05 µF (21105), 2100 VAC, 50/60 Hz capacitor with ±3% tolerance and 6.35 x 0.8 mm / 1/4 in standard terminals. The capacitor is marked No PCB and includes a built-in 10 MΩ discharge resistor. CQC and VDE certification to EN61270-1 is stated for this CH85 capacitor. Use it as a replacement for GE WB27X10701 or other microwave capacitors only when the capacitance, voltage, terminal size and mounting requirements match your original part. Microwave capacitors can retain high voltage after power is disconnected; disconnect power and discharge the capacitor before service.

• CH85 microwave high voltage capacitor for household microwave oven repair; 1.05 µF (21105), 2100 VAC, 50/60 Hz, ±3% tolerance.
• Standard CH85 module type with 6.35 x 0.8 mm / 0.25 x 0.03 in terminals, also known as 1/4 in standard terminals; No PCB.
• Built-in 10 MΩ discharge resistor as stated for the capacitor design. Disconnect power and discharge the capacitor before service.
• Replacement for GE WB27X10701 and other microwave capacitors only when capacitance, voltage, terminal size and mounting requirements match the original part.
• Check the markings on your old capacitor before ordering. This high-voltage component should be installed by a qualified person.
